Game of thrones S7 Logo



 First of all go to Inventables   https://www.inventables.com/
 and then sign in to your account and launch Easel.

Download this image below and go to "Import" and then to "Image Trace"
When the image trace is complete, click on the "Invert" option and then click on import.




Resize to your dimensions and depth to 2mm. Select material MDF or you can choose your and bit size to 1/8 inch (straight cut) and Simulate




Crave it .....!


After the curving, sand the edge little bit with sandpaper. Color the engrave letter with your favourite color. #GOT S7




This is all for GOT fan I hope you might like it.
